Metal Energy Absorber System

Products / Horizontal Lifelines (HLL)

Product images are representative only.


A permanent cable HLL system

The Guardian-exclusive Metal Energy Absorber is designed for cable HLL systems utilizing dual 5000 lbs. anchorage connectors. The unique spiral design quickly sheds arrest energy minimizing felt impact forces during a fall. The Metal Energy Absorber can be used in cable HLL systems up to 100’. Use (1) Metal Energy Absorber on systems up to 60’ and (2) Metal Energy Absorbers (one at each anchorage connector) on systems between 60’ and 100’.

If known, input the specific Part Number here of a pre-configured product:



Features

  • Guardian-exclusive design
  • Stainless steel construction
  • For use with HLLs only
  • Use (1) Metal Energy Absorber on systems up to 60’, and (2) Metal Energy Absorbers (one at each anchorage connector) on systems between 60’ and 100’.


Specifications

Product weight

11LB / 4.99KG

Product length

20'' / 50.80CM

Product height

1'' / 2.54CM


Compliance

This product meets the following regional compliance standards

  • OSHA 1926 Subpart M

  • OSHA 1910

  • ANSI A10.32 regulations.


Industries

This product is often used in the following industries

  • Construction
  • Mining
  • Transportation
  • Telecoms
  • General Industry
  • Renewables
